The gantry inverted three-axis mobile device mainly consists of X-axis sliding platform, Y-axis sliding platform, Z-axis sliding platform, inverted hanging arm, gantry, servo drive mechanism and control system. The mechanical arm adopts gantry upside-down installation, which saves the floor space and expands the external axis in the three directions of length, width and height, greatly increasing the welding range of the robot, and is often used for welding workpieces with large space size and welding and handling of multi-station workpieces.

Three-dimensional space movement can be realized. FSL120 is a closed screw module. Effective stroke ≤ 1200MM, sliding table side with stainless steel seal, waterproof and dustproof grade: IP51. Internal configuration of double guide rail, a total of 4 slides. Suitable for heavy loads and high speeds.
Closed double guide ball screw three-axis slide table (gantry type) is a three-axis motion system built by Fuyu FSL120 series linear modules. Three-dimensional space movement can be realized. FSL120 is a closed screw module. Effective stroke ≤ 1200MM, sliding table side with stainless steel seal, waterproof and dustproof grade: IP51. Internal configuration of double guide rail, a total of 4 slides. Suitable for heavy loads and high speeds.

Y axis: effective stroke ≤ 1200MM
X axis: effective stroke ≤ 1200MM
Z axis: effective stroke ≤ 600MM
Maximum load: less than 50KG (according to the effective stroke of the X axis, the longer the load, the smaller)
Specific use, according to the specific use of the environment, accuracy, speed, load, etc., please contact our customer service, pre-sale technical engineer appointment!

Gantry inverted three-axis mobile device is part of DUOYUAN's work on automotive manufacturing equipment engineered for a specific vehicle and plant. The page shows the equipment family and project images. Rated load, speed, material range and cycle time are confirmed in the engineering review for that vehicle and plant. They are not fixed catalog values.

Questions before a technical review

What is this equipment page for?
It identifies the equipment family and shows related project images. The build specification is issued after DUOYUAN reviews the part, process and plant.
Are capacity, speed and material range published as fixed specifications?
No. DUOYUAN confirms rated load, line speed, material grade and cycle time during the engineering review. A category page does not state a payload, thickness or tolerance that applies to every project.
What should a buyer send with an inquiry?
Send the vehicle or part, the process step, the target plant and any layout constraints to info@zzdy.cn or call +86-371-62138138. The engineering team replies with the project scope. Do not treat marketing copy on this site as a guaranteed technical parameter.
