Spot welding workstation

After the weldment is combined, the pressure is applied through the electrode, and the resistance heat generated by the current flowing through the welding zone is used to heat the workpiece, so that the welding part can reach a local melting or high temperature plastic state, and the connection is completed through the combined action of thermal and mechanical forces.

Using the resistance heat of the welding zone metal itself and a large amount of plastic deformation energy, the metal atoms of the two separate surfaces are close to the lattice distance, forming metal bonds, and producing a sufficient amount of common grains on the joint surface to obtain solder joints, welds or butt joints.

Spot welding workstation is part of DUOYUAN's work on body welding lines, robotic welding stations, fixtures and positioners. The page shows the equipment family and project images. Rated load, speed, material range and cycle time are confirmed in the engineering review for that vehicle and plant. They are not fixed catalog values.

Questions before a technical review

What does a DUOYUAN welding package usually include?
Depending on the project, the scope can include the welding line or station, fixtures, positioners, robot integration and commissioning. The exact package is defined in the technical agreement, not by this page.
Are capacity, speed and material range published as fixed specifications?
No. DUOYUAN confirms rated load, line speed, material grade and cycle time during the engineering review. A category page does not state a payload, thickness or tolerance that applies to every project.
What should a buyer send with an inquiry?
Send the vehicle or part, the process step, the target plant and any layout constraints to info@zzdy.cn or call +86-371-62138138. The engineering team replies with the project scope. Do not treat marketing copy on this site as a guaranteed technical parameter.
